Adapter BCS POINT BCS-P-A81

The BCS POINT BCS-P-A81 is a compact and reliable Power over Ethernet (PoE) adapter designed to deliver both data and power over a single Ethernet cable. Compliant with IEEE 802.3af standard, it provides 48V DC output at 0.5A (24W) to power PoE-enabled devices such as IP cameras, wireless access points, and VoIP phones. With integrated EU Type C/F plug, it is ideal for European markets.

Advantages

Simplifies installation by eliminating the need for separate power cables near devices. Supports Fast Ethernet (10/100 Mbps) data rates, ensuring compatibility with most network equipment. Built-in overload and short circuit protection safeguards connected devices.

Suitable for

• Powering IP cameras, VoIP phones, and wireless access points
• Extending network reach where power outlets are limited
• Small office/home office (SOHO) and enterprise network deployments

Key specifications

• PoE Standard: IEEE 802.3af
• Input: 100-240V AC, 50/60 Hz
• Output: 48V DC, 0.5A, 24W
• Data Rate: 10/100 Mbps (Fast Ethernet)
• Ports: 1x RJ45 Data In, 1x RJ45 Data+Power Out
• LED Indicator: Power (Green)
• Operating Temperature: -10°C to 45°C
• Storage Temperature: -20°C to 70°C
• Humidity: 5% to 90% non-condensing
• Housing: Plastic
• AC Plug: Integrated EU Type (Type C/F compatible)

Recommendations

For optimal performance, use with standard Cat5e or higher Ethernet cables. Ensure the total power consumption of connected devices does not exceed 24W.
