DIGITUS OnLine UPS modul 2000VA / 2000W

DIGITUS OnLine UPS modul 2000VA / 2000W
DIGITUS OnLine UPS modul 2000VA / 2000W
DIGITUS OnLine UPS modul 2000VA / 2000W
DIGITUS OnLine UPS modul 2000VA / 2000W
DIGITUS OnLine UPS modul 2000VA / 2000W
DIGITUS OnLine UPS modul 2000VA / 2000W
DIGITUS OnLine UPS modul 2000VA / 2000W
DIGITUS OnLine UPS modul 2000VA / 2000W
DIGITUS OnLine UPS modul 2000VA / 2000W
DIGITUS OnLine UPS modul 2000VA / 2000W
504,03 €
The OnLine UPS is an ideal backup solution for your demanding power requirements and offers high reliability in various industrial applications.- High power factor (1.0), a higher active power enables more connected loads, which saves space and reduces costs.- High efficiency in online mode, higher ... Preberi več
Zaloga 1 Šifra izdelka 300091 Znamka DIGITUS Model DN-170095 Garancija 2 leti
KategorijaOnline UPS

Dostava in vračila

Predvidena dostava četrtek, 5. november
O stanju vas bomo sproti obveščali prek našega podrobnega sistema za sledenje
Možnosti plačila
Bančna karticaVisaMastercardPayPalApple PayGoogle PayBančno nakazilo

The OnLine UPS is an ideal backup solution for your demanding power requirements and offers high reliability in various industrial applications.

- High power factor (1.0), a higher active power enables more connected loads, which saves space and reduces costs.
- High efficiency in online mode, higher efficiency means optimized energy management and lower heat dissipation, resulting in energy savings and improved reliability.
- User-friendly LCD screen provides insight into UPS status for easy installation, configuration and operation.
- Compact rack/tower design optimizes the installation space in the rack and enables flexible installation.
- Minimize device downtime with hot-swappable, user-replaceable battery modules that can be replaced during operation.
- External battery modules allow the runtime to be extended.
- High number of outlets (8 x C13) for optimum power distribution to the consumers.
- Various communication interfaces (RS232/USB, parallel port, SNMP slot) enable remote monitoring of the system.
- Automatic battery self-test and fan speed control increase the service life of the components.
- The REPO function (Remote Emergency Power Off) switches the UPS off in the event of an emergency. If an emergency occurs, the REPO switch turns off the rectifier and the inverter and immediately stops the power supply to the load. The UPS stops charging.

The DIGITUS® OnLine UPS is a double-conversion UPS solution that offers first-class power failure protection and continuous power generation in a compact and flexible system. The single-phase UPS operates with high energy efficiency and is ideal for protecting critical infrastructure in both centralized and edge network applications. Scalable runtime options with matching external battery cabinets provide additional flexibility when a longer uninterruptible power supply is required. The user-friendly LCD display and network management capability, including configuration, make this system easy to install and maintain. With market-leading efficiency and unity power factor, the UPS meets your critical application requirements.

Ključne značilnosti
  • Online double conversion system (VFI-SS-111)
  • Input: IEC60320 C20 socket, 208/220/230/240 Vac
  • Output: 8 x IEC60320 C13, max. 10A per socket outlet
  • Nominal system power: 2000 VA / 2000 W, power factor 1.0
  • AC-AC (online VFI) efficiency: 93 %, ECO mode efficiency: 98 %.
  • Internal battery pack can be replaced during operation.
  • Battery: Valve-protected, non-spillable lead-acid battery
  • Battery quantity: 4 x 12V x 9.0 Ah
  • Charging: 4 hours to 90% capacity after full discharge
  • Network connection: Optional SNMP/Webcard (part number DN-170100) enables the UPS to be monitored remotely.
  • Local communication ports: USB, RS-232 (serial), SNMP card (optional), relay card (optional)
  • Emergency Power-off (EPO) contact for switching off the UPS in an emergency
  • Maximum operating temperature: 0 - 40 °C
  • Storage temperature: -25 - 55 °C
  • Relative humidity: 20 - 90% non-condensing
  • Operating altitude: < 1500 m
  • Product dimensions WxDxH (mm): 440 (19") x 460 x 86.5 (2U)
  • Product weight: 19.5 kg
  • Shipping dimensions WxDxH (mm): 560 x 590 x 200
  • Shipping weight: 23.7 kg
  • Safety standards: IEC/EN62040-1,IEC/EN60950-1
  • EMC standards: IEC/EN62040-2,IEC61000-4-2,IEC61000-4-3,IEC61000-4-4, IEC61000-4-5,IEC61000-4-6,IEC61000-4-8
  • Optionally available: 19" UPS mounting kit (profile rails), article number DN-170109
  • IP protection class: IP21
  • Heat dissipation: 614 BTU/h
  • Noise level in online mode: approx. 50 dB(A) at a distance of 1 m (may vary slightly depending on load and ambient temperature).
Specifikacije
Barva izdelka
Črna
Carinska oznaka UK Trade Tariff
85044085
Čas polnjenja baterije (90 %)
4 h
Delovna nadmorska višina
0 - 1500 m
Delovna temperatura (T-T)
0 - 40 °C
Delovna vhodna napetost (min.)
208 V
Država porekla
Kitajska
Faktor moči
1
Globina
460 mm
Globina embalaže
595 mm
Izhodna moč
2000 W
Izhodna zmogljivost moči
1.5 kVA
Kapaciteta baterije
9 Ah
Komplet za montažo v rack
Da
Največji tok
10 A
Napetost baterije
12 V
Oblikovni faktor
Za vgradnjo v omaro
Omrežni vtič
C20 coupler
Priključek USB
Da
Priključek za zasilni izklop (EPO)
Da
Priključki Ethernet LAN (RJ-45)
2
Priloženi kabli
RS-232, USB cable
Priročnik
Da
Prostornina paketa
66705.5 cm³
Relativna vlažnost med delovanjem (H-H)
20 - 90%
Relativna vlažnost pri skladiščenju (H-H)
20 - 90%
Širina
440 mm
Širina paketa
555 mm
Snemljiv napajalni kabel
Da
Število izhodov AC
8 AC outlet(s)
Število podprtih baterij
4
Število serijskih priključkov
1
Temperatura shranjevanja (T-T)
-25 - 55 °C
Teža
19.5 kg
Teža paketa
22.9 kg
Topologija UPS
Dvojna pretvorba (online)
Učinkovitost
93%
Učinkovitost (način ECO)
98%
Velikost (palci)
48.3 cm (19")
Vgrajen ventilator
Da
Vhodna delovna napetost (maks.)
240 V
Višina
86.5 mm
Višina paketa
200 mm
Vrsta hlajenja
Aktivno
Vrsta priključka USB
USB Type-B
Vrsta serijskega vmesnika
RS-232
Vrsta vira napajanja
AC
Vrsta zaslona
LCD
Vrste vtičnic AC
C13 coupler
